Main technical parameters of PVD hard coating machine

NO.

Function items

Model GTDT-01

Model GTDT-02

Model GTDT-03

1

Number of targets that can be installed

2 sets of different targets (4 in a set)

3 sets of different targets (3 in a set)

3 sets of different targets (4 in a set)

2

Effective coating area

Ф700*800mm

Ф800*700mm

Ф800*800

3

Turret load-bearing capacity

800KG

800KG

800KG

4

Maximum heating temperature

600℃

5

Coating type

TiN,CrN,TiCN,TiAlN,AlTiN,AlCrN and other single or multi-layer hard coatings

6

Coating cycle

8-10h/furnace

6-8h/furnace

8-10h/furnace

7

Technical features

1.Dual magnetic field driven magnetic system. 2.Unique enhanced ion etching technology
